3M Dichroic Blaze (DFPA/DF-PA) 48″ Wide Roll
3M Dichroic Blaze (DFPA-Blaze) is a durable film with a pressure-sensitive adhesive that is available as a full roll (48″ X 98.4′), partial roll (sold by the linear foot)
3M’s value-engineered dichroic film installed on clear glass duplicates the look of dichroic glass at a small fraction of the price of the real thing.
- Colors shifts colors in the warm tones of cyan/blue/magenta in transmission and red/gold color regions of the spectrum in reflection
- The product appears to change color when viewed at various angles
- A hard-coated surface layer helps resist scratching
- Wet application virtually eliminates air bubbles, simplifying and speeding up application
- Glass Doors
- Windows
- Conference Rooms
- Lobbies
- Retail Environments
- Glass Partitions
- Verandas
- Private Offices
- Hallways
- Staircases
- Balconies
- Exhibits
|
Attribute
|
Value
|
|---|---|
|
Manufacturer
|
3M Company
|
|
3M Product Name
|
Dichroic Blaze
|
|
3M Product ID
|
DFPA-Blaze
|
|
Film Color
|
Cyan/Blue/Magenta in transmission and Red/Gold color regions of the spectrum in reflection
|
|
Visible Light Transmission
|
77%
|
|
Shading Coefficient
|
.70
|
|
UV Rejection
|
97.4%
|
|
Full Roll Size
|
48” X 98.4’ (1,219 mm X 30 m)
|
|
Film Thickness
|
5.2 mils (132 microns)
|
|
Base Material
|
Multi-Layer Polymeric
|
|
Adhesive Type
|
Pressure Sensitive
|
|
Adhesive Color
|
Clear
|
